Prama PT-NR2A04-Q1 4 Channel NVR

PT-NR2A04-Q1 4-Ch 4K Network Video Recorder

• H.265+/H.265/H.264/H.264+ video formats • Connectable to the third-party network cameras • Up to 16 IP cameras can be connected • Recording at up to 8 MP resolution • Live view, storage, and playback of the connected camera at up to 8 MP resolution

Brand : Prama
Category : CCTV Surveillance System, NVR


VIDEO/AUDIO OUTPUT

  • Recording resolution“8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA /720p/VGA/4CIF/DCIF/
    2CIF/CIF/QCIF”
  • HDMI output resolution“1-ch, 4K (3840 × 2160)/30Hz,
    1920 × 1080p/60Hz, 1600 ×
    1200/60Hz, 1280 ×
    1024/60Hz, 1280 × 720/60Hz,
    1024 × 768/60Hz;
    HDMI/VGA simultaneous output”
  • VGA output resolution“1-ch, 1920 × 1080p/60Hz,
    1600 × 1200/60Hz, 1280 ×
    1024/60Hz, 1280 × 720/60Hz,
    1024 × 768/60Hz; HDMI/VGA
    simultaneous output”
  • Audio output1-ch, RCA (Linear, 1 KΩ)

DECODING

  • Decoding formatH.265/H.265+/H.264/H.264+/MPEG4
  • Live view / Playback resolution“8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA /720p/VGA/4CIF/DCIF/
    2CIF/CIF/QCIF”
  • Synchronous playback4-ch
  • Capability1-ch @ 8 MP / 4-ch @ 1080p

NETWORK MANAGEMENT

  • Network protocolsTCP/IP, DHCP, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS

HARD DISK

  • SATA1 SATA interface
  • CapacityUp to 6TB capacity for each disk

EXTERNAL INTERFACE

  • Network interface1, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
  • USB interface2 × USB 2.0

GENERAL

  • Power supply12 VDC
  • Power≤ 18W
  • Consumption (without hard disk)≤ 10 W
  • Working temperature-10 to +55º C (+14 to +131º F)
  • Working humidity10 to 90%
  • Chassis1U chassis
  • Dimensions (W × D × H)315 × 240 × 48 mm (12.4inch × 9.4inch× 1.9inch)
  • Weight(without hard disk)≤ 1 kg (2.2 lb)

NETWORK

  • Incoming bandwidth40 Mbps
  • Outgoing bandwidth80 Mbps

VIDEO/AUDIO OUTPUT

  • Recording resolution“8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA /720p/VGA/4CIF/DCIF/
    2CIF/CIF/QCIF”
  • HDMI output resolution“1-ch, 4K (3840 × 2160)/30Hz,
    1920 × 1080p/60Hz, 1600 ×
    1200/60Hz, 1280 ×
    1024/60Hz, 1280 × 720/60Hz,
    1024 × 768/60Hz;
    HDMI/VGA simultaneous output”
  • VGA output resolution“1-ch, 1920 × 1080p/60Hz,
    1600 × 1200/60Hz, 1280 ×
    1024/60Hz, 1280 × 720/60Hz,
    1024 × 768/60Hz; HDMI/VGA
    simultaneous output”
  • Audio output1-ch, RCA (Linear, 1 K?)

DECODING

  • Decoding formatH.265/H.265+/H.264/H.264+/MPEG4
  • Live view / Playback resolution“8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA /720p/VGA/4CIF/DCIF/
    2CIF/CIF/QCIF”
  • Synchronous playback4-ch
  • Capability1-ch @ 8 MP / 4-ch @ 1080p

NETWORK MANAGEMENT

  • Network protocolsTCP/IP, DHCP, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS

HARD DISK

  • SATA1 SATA interface
  • CapacityUp to 6TB capacity for each disk

EXTERNAL INTERFACE

  • Network interface1, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
  • USB interface2 × USB 2.0

GENERAL

  • Power supply12 VDC
  • Power? 18W
  • Consumption (without hard disk)? 10 W
  • Working temperature-10 to +55º C (+14 to +131º F)
  • Working humidity10 to 90%
  • Chassis1U chassis
  • Dimensions (W × D × H)315 × 240 × 48 mm (12.4inch × 9.4inch× 1.9inch)
  • Weight(without hard disk)? 1 kg (2.2 lb)


NETWORK

  • Incoming bandwidth40 Mbps
  • Outgoing bandwidth80 Mbps

VIDEO/AUDIO OUTPUT

  • Recording resolution“8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA /720p/VGA/4CIF/DCIF/
    2CIF/CIF/QCIF”
  • HDMI output resolution“1-ch, 4K (3840 × 2160)/30Hz,
    1920 × 1080p/60Hz, 1600 ×
    1200/60Hz, 1280 ×
    1024/60Hz, 1280 × 720/60Hz,
    1024 × 768/60Hz;
    HDMI/VGA simultaneous output”
  • VGA output resolution“1-ch, 1920 × 1080p/60Hz,
    1600 × 1200/60Hz, 1280 ×
    1024/60Hz, 1280 × 720/60Hz,
    1024 × 768/60Hz; HDMI/VGA
    simultaneous output”
  • Audio output1-ch, RCA (Linear, 1 KΩ)

DECODING

  • Decoding formatH.265/H.265+/H.264/H.264+/MPEG4
  • Live view / Playback resolution“8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA /720p/VGA/4CIF/DCIF/
    2CIF/CIF/QCIF”
  • Synchronous playback4-ch
  • Capability1-ch @ 8 MP / 4-ch @ 1080p

NETWORK MANAGEMENT

  • Network protocolsTCP/IP, DHCP, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS

HARD DISK

  • SATA1 SATA interface
  • CapacityUp to 6TB capacity for each disk

EXTERNAL INTERFACE

  • Network interface1, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
  • USB interface2 × USB 2.0

GENERAL

  • Power supply12 VDC
  • Power≤ 18W
  • Consumption (without hard disk)≤ 10 W
  • Working temperature-10 to +55º C (+14 to +131º F)
  • Working humidity10 to 90%
  • Chassis1U chassis
  • Dimensions (W × D × H)315 × 240 × 48 mm (12.4inch × 9.4inch× 1.9inch)
  • Weight(without hard disk)≤ 1 kg (2.2 lb)
